Every construction project has its own cable management specification. Commercial high-rises need lightweight galvanized trays. Industrial plants demand heavy-gauge hot-rolled steel. Infrastructure tunnels require corrosion-resistant profiles. The question is not whether your machine can handle one of these — it is whether it can handle all of them.
The HOPEX perforated type cable tray roll forming machine is the answer. With a 194–814mm feeding width, 1.2–2.0mm thickness range, and three compatible material grades, this single line covers the full spectrum of perforated cable tray production.
Application Scenario 1: Commercial Building Construction
Product Spec: Lightweight galvanized perforated trays, narrow width, fine hole pattern
Production Setting: High-volume, standardized output
Commercial office towers and retail complexes require thousands of meters of cable trays — consistent quality, uniform appearance, and on-time delivery.
How this machine delivers
- Delta/Schneider PLC ensures tray-to-tray dimensional repeatability
- 31-roller progressive forming maintains clean, burr-free edges essential for installer safety
- 3-meter finished product length matches standard commercial installation modules
- Galvanized steel compatibility means pre-coated corrosion protection with no post-processing
Application Scenario 2: Industrial Facility Projects
Product Spec: Heavy-gauge hot-rolled steel trays, wide profile, dense perforation
Production Setting: High-durability, load-bearing output
Factories, warehouses, and processing plants route substantial cable bundles across long spans. Trays must carry weight and resist deformation.
How this machine delivers
- 0mm maximum rolling thickness handles heavy-gauge Q235B hot-rolled strip steel
- 814mm maximum feeding width produces wide-profile trays for high-capacity cable runs
- Hydraulic station with 46# hydraulic oil delivers consistent punching force even at maximum material thickness
- 18# hypoid gear oil in the transmission sustains torque under continuous heavy-load production
Application Scenario 3: Infrastructure & Utility Works
Product Spec: Mid-gauge cold-rolled or galvanized trays, custom perforation, large order volumes
Production Setting: Project-specific, long-run production
Tunnels, metros, power plants, and data centers present the most demanding cable management environments — heat, moisture, and strict regulatory compliance.
How this machine delivers
- Q235B cold-rolled strip steel option for controlled surface finish and dimensional tolerance
- Versatile perforation options to meet airflow and fire-safety regulations
- Energy-saving design reduces operating overhead on extended production runs
- Online after-sales support ensures rapid troubleshooting during critical project timelines
Key Specifications at a Glance
| Parameter | Value |
| Type | Roll Forming Machine |
| Tile Type | Steel |
| Feeding Width | 194–814 mm (7.64–32.05 in) |
| Rolling Thickness | 1.2–2.0 mm (0.05–0.08 in) |
| Voltage | 380 V |
| Rollers | 31 rollers |
| Control System | Delta / Schneider |
| Operate Style | Hydraulic Station |
| Hydraulic Oil | 46# hydraulic oil |
| Gear Oil | 18# hypoid gear oil |
| Finished Product Length | 3 meters |
| Suitable Material | Q235B cold-rolled strip steel, hot-rolled strip steel, galvanized |
| Dimension (L×W×H) | 20000 × 1500 × 1600 mm (787.40 × 59.06 × 62.99 in) |
| Weight | 50000 kg (110231.13 lb) |
| Core Components | Engine, PLC, Gear, Bearing, Motor, Pressure Vessel |
| Warranty | 2 Years |
| After-sales Service | Online Support |
| Video Outgoing-Inspection | Provided |
| Machinery Test Report | Provided |
| Place of Origin | Tianjin, China |
| Brand Name | hopx-cable tray punching hole machine |
| Application | Building Construction |
| Key Selling Points | Energy Saving |
Packaging & Delivery
| Parameter | Value |
| Selling Units | Single item |
| Single Package Size | 20000 × 1500 × 1600 cm |
| Single Gross Weight | 20000.000 kg |
Why This Machine Fits Your Product Portfolio
Cover More Market Segments with One Investment
A single perforated type cable tray roll forming machine that spans 194–814mm width and three material grades means you can bid on commercial, industrial, and infrastructure projects without retooling or adding production lines.
Consistent Quality Across Every Tray
The 31-roller forming architecture, synchronized with the Delta/Schneider control system, ensures that tray #1 and tray #10,000 are dimensionally identical. Your clients receive uniform product quality — every order, every time.
Built to Outlast Project Cycles
With a 2-year warranty, pressure vessel-grade hydraulics, and bearings selected for continuous industrial duty, this machine is engineered for multi-year production schedules, not seasonal campaigns.
Energy Efficiency That Compounds
Operating across multiple shifts? The energy-saving hydraulic design reduces per-tray electricity consumption. Over months of continuous production, the savings become a meaningful margin advantage.
Production Workflow
Raw Coil → Leveling → Perforation Punching → 31-Roller Forming → Cut-to-Length → Finished Tray
Every stage monitored and synchronized by the Delta/Schneider PLC control system.
Frequently Asked Questions
Which material should I choose for my target market?
Galvanized for commercial and outdoor applications. Cold-rolled Q235B for premium indoor installations. Hot-rolled for heavy-duty industrial use. All three are supported.
Can I switch between tray widths without long downtime?
Yes. The feeding width range of 194–814mm allows width changes through control system parameter adjustment. Consult our engineering team for changeover procedures.
What after-sales coverage is included?
2-year warranty with online support. Video outgoing-inspection and machinery test report provided before shipment.
Does the machine support non-standard hole patterns for specific regional standards?
The versatile perforation system accommodates various hole configurations. Provide your pattern specifications for engineering verification.
Tell Us About Your Market
Whether you serve commercial contractors, industrial EPC firms, or infrastructure project owners — we will help you configure the right perforated cable tray production solution.
